Feature Specification
Small Form Factor none
PCI Express x1 data width (maximum) – one PCI Express lane
Mini-Tower one 36-pin connector
Small Form Factor none
PCI Express x16 (wired as x4) data width (maximum) – four PCI Express lanes
Mini-Tower one 164-pin connector
Small Form Factor one 64-pin connector
PCI Express x16 data width (maximum) – 16 PCI Express lanes
Mini-Tower, Small Form Factor one 164-pin connector
Mini PCI Express data width (maximum) – one PCI Express lane and one USB interface
Mini-Tower, Small Form Factor none
Serial ATA:
Mini-Tower four 7-pin connectors
Small Form Factor three 7-pin connectors
Memory:
Mini-Tower, Small Form Factor four 240-pin connectors
Internal USB:
Mini-Tower one 10-pin connector
Small Form Factor none
System Fan one 5-pin connector
Front panel control:
Mini-Tower
• one 6–pin connector
• two 20–pin connector
Small Form Factor
• one 6-pin connector
• one 10-pin connector
• one 12-pin connector
• one 20-pin connector
Thermal Sensor:
Mini-Tower one 2-pin connector
Small Form Factor none
Processor one 1150-pin connector
Processor Fan one 5-pin connector
Service mode jumper one 2-pin connector
55
