Dell OptiPlex 7060 Micro - 2.5-inch Hard Drive Assembly

2 Follow the procedure in After working inside your computer.
2.5-inch hard drive assembly
Removing 2.5–inch hard drive assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the Side cover.
3 To remove the drive assembly:
a Press the blue tabs on both sides of the hard drive assembly [1].
b Push the hard drive assembly to release it from the system and remove the hard drive assembly from the system [2].
14
Disassembly and reassembly
