Video
• Two DisplayPorts (rear)
• DisplayPort/HDMI 2.0b/VGA/USB Type-C Alt-Mode (optional)
(rear)
Network adapter One RJ-45 (10/100/1000) connector
Serial port One serial port (optional) (rear)
System board connectors
Table 11. System board connectors
M.2 Connectors
• 1 - 2230/2280
• 1 - 2230 (keyed to support Integrated or Discrete WiFi, Support
Intel CNVi or USB2.0/PCIe)
Serial ATA (SATA) connector 3 (one Gen2 port for ODD and the rest of the ports support Gen3)
PCIe X16 slot 1 (Support Standard Rev 3.0)
PCIe X1 slot 0
PCIe X16 slot (wired x4) slot 0
PCIe X4 1 (open ended X4 to support X16)
Operating system
Table 12. Operating system
Operating systems supported
• Windows 10 Home (64-bit)
• Windows 10 Pro (64-bit)
• Windows 10 Pro National Academic (64-bit)
• Windows 10 Home National Academic (64-bit)
• Ubuntu 16.04 SP1 LTS (64-bit)
• Neokylin v6.0 SP4 (China only)
Power supply
Table 13. Power supply
Input Voltage 90-264 Vac
Input current (maximum)
3.2A
Wattage 90W / 130 W
NOTE: System with 65 W CPU is shipped with 130W PSU.
14 System specications
