Dell OptiPlex 960 - Detailed Engineering Specifications; System Dimensions ( Physical ); System Board Connector Maximum Allowable Dimensions

DELL™ OPTIPLEX™ 960 TECHNICAL GUIDE
18
DETAILED ENGINEERING SPECIFICATIONS
SY S T EM DIM E N S I ONS ( P HY SI C AL )
NO T E : S ys tem W e i g ht* a n d S h i pp i n g W e i g h t * is ba s e d on a typ i c a l c o n f i g u ra t i o n a n d ma y va r y b a s e d o n PC
co n f i g u r at i o n .
SY S T EM B O A R D C O N NE C T O R M A XIM UM ALL OW A B LE DIM E N S IO NS
*Maximum allowable dimensions for full height card options installed in riser within the desktop chassis
**These dimensions are for a standard low profile card installed in the desktop/sff chassis
MT DT SFF
Chassis Volume liters
32.62 15.08 8.00
Chassis Weight pounds/kilograms
25.3lbs/ 11.5kg 16.5lbs/ 7.5kg 13.0lbs/ 5.9kg
Chassis Dimensions: (HxWxD)
Height inches/centimeters 16.06in/40.80cm 15.61in/39.65cm 11.40in/28.96cm
Width inches/centimeters 7.36in/18.70cm 4.30in/10.93cm 3.35in/8.52cm
Depth inches/centimeters 16.96in/43.08cm 13.70in/34.80cm 12.74in/32.36cm
Packaging Parameters (HxWxD)
Height inches/centimeters 22.06/ 56.0 20.35/ 51.7 20.75/ 52.7
Width inches/centimeters 20.94/ 53.2 20.04/ 50.9 16.38/ 41.6
Depth inches/centimeters 14.56/ 37.0 11.96/ 30.4 11.25/ 28.6
MT DT SFF
PCIe x16 Slot Dimensions [slot 1]: (HxL)
1
1 1
Height inches/mm 4.37 [111.15] 2.731 [68.90]**
Length inches/mm 7.40 [187.96) 6.600 [167.64]**
PCI Slot Dimensions [slot 2]: (HxL)
1 1 1
Height inches/mm 4.37 [111.15] 2.731 [68.90]**
Length inches/mm 7.40 [187.96) 6.600 [167.64]**
PCI Slot Dimensions [slot 3]: (HxL)
1 1 0
Height inches/mm 4.37 [111.15] 2.731 [68.90]**
Length inches/mm 6.60 [167.64] 6.600 [167.64]**
PCIe x1 Slot Dimensions [slot 4]: (HxL)
1
1 0
Height inches/mm 4.37 [111.15] 2.731 [68.90]**
Length inches/mm 6.60 [167.64] 6.600 [167.64]**
PCIe Wireless Connector x1 Slot
1 1 1
Risers: (replaces PCIe x16 slot 1 and PCI slot 2 on DT system board)
Combo Full Height Riser with 1 PCI and 1 PCIe connector* (HxL)
1
Height inches/mm 4.37/111.15*
Length inches/mm 6.60/167.64*
Dual Full Height Riser with 2 PCI connectors* (HxL)
1
Height inches/mm 4.37/111.15*
Length inches/mm 6.60/167.64*
