Dell OptiPlex 960 - Audio

DELL™ OPTIPLEX™ 960 TECHNICAL GUIDE
20
MT
APFC EPA
DT
APFC EPA
SFF
APFC EPA
BTUs/h (based on PSU max
wattage)
560 BTU 153.5 BTU 477 BTU 153.5 BTU 433 BTU 153.5 BTU
3.3v CMOS battery (type
and estimated battery life)
3-V CR2032 lithium coin cell. Minimum est. 5 year life
Power Supply Fan
80 x 25mm 80 x 25mm 92 x 25mm 92 x 25mm
80 x 15mm
or
80 x 20mm
80 x 15mm
or
80 x 20mm
Compliance:
Energy Star Compliant No Yes No Yes No Yes
Blue Angel Compliant Yes Yes Yes Yes Yes Yes
Climate Savers / 80Plus
Compliant
No Silver No Silver No Silver
FEMP Standby Power Com-
pliant
Yes Yes Yes Yes Yes Yes
PO W E R (C O NT . )
INTEGRATED ADI 1984A HIGH DEFINITION AUDIO
MT DT SFF
High Definition Stereo support
X X X
Number of channels
2
Number of Bits / Audio resolution
16, 20, and 24-bit resolution
Sampling rate (recording/playback)
Independent 8, 11.025, 16, 22.05, 32, 44.1,
48, 88.2, 96, 176.4, and 192 kHz sample rates
Signal to Noise Ratio
96+ dB audio outputs, 90+ dB audio inputs
Analog Audio
X X X
Dolby Digital
THX
Digital out (S/PDIF)
Audio Jack Impedance
Microphone 150 kΩ
Line-In 150 kΩ
Line-Out 190 Ω
Headphone .5 Ω
Internal Speaker Power Rating
2W
AUD IO
