Table 47. 2.5-inch, 500 GB, 7200 RPM, SATA, HDD specifications (continued)
Relative humidity range 5% to 95%
2.5-inch, 500 GB, 7200 RPM, SATA, HDD, Self-Encrypting, Opal
2.0, FIPS
Table 48. 2.5-inch, 500 GB, 7200 RPM, SATA, HDD, Self-Encrypting, Opal 2.0, FIPS specifications
Capacity 500 GB
Speed 7200 RPM OPAL SED FIPS
Height (approximate) 7.11 mm (0.28 in.)
Width (approximate) 69.85 mm (2.75 in.)
Depth (approximate) 100.58 mm (3.96 in.)
Interface SATA 3.0
Speed (maximum) Up to 6 Gbps
MTBF 550,000 hours
Logical blocks 976,773,168
Power source
Power consumption (reference only)
● Idle: 0.7 W
● Active: 3.25 W
Environmental operating conditions (non-condensing)
Temperature range 5°C to 60°C
Relative humidity range 5% to 90%
Op shock 350G @2ms
Environmental non-operating conditions (non-condensing)
Temperature range -40°C to 65°C
Relative humidity range 5% to 95%
M.2 2230, 256 GB, PCIe NVMe Gen3 x4, Class 35 SSD
The following table lists the M.2 2230, 256 GB SSD specifications.
Table 49. 256 GB SSD specifications
Capacity 256 GB
Height (approximate) 2.38 mm (0.09 in.)
Width (approximate) 22.00 mm (0.87 in.)
Depth (approximate) 30.00 mm (1.18 in.)
Interface type PCIe Gen3
Speed (maximum) 32 Gb/s (up to 4 lanes)
MTBF 1.4M hours
Logical blocks 500,118,192
Power source
Engineering specifications 39
