Dell P148G - Power Adapter Specifications; Battery Specifications

Power adapter
The following table lists the power adapter specifications of your Latitude 5430 Rugged.
Table 18. Power adapter specifications
Description Option one Option two
Type
Pecos 65 W AC adapter, USB-C 90 W AC adapter, USB-C
Power-adapter dimensions:
Height
28.00 mm (1.10 in.) 22.00 mm (0.87 in.)
Width
51.00 mm (2.01 in.) 66.00 mm (2.60 in.)
Depth
112.00 mm (4.41 in.) 130.00 mm (5.12 in.)
Input voltage
100 VAC to 240 VAC 100 VAC to 240 VAC
Input frequency
50 Hz to 60 Hz 50 Hz to 60 Hz
Input current (maximum)
1.5 A 1.8 A
Output current (continuous)
● 20 V/3.25 A
● 15 V/3 A
● 9 V/3 A
● 5 V/3 A
● 20 V/4.50 A
● 15 V/3 A
● 9 V/3 A
● 5 V/3 A
Rated output voltage
● 20 VDC
● 15 VDC
● 9 VDC
● 5 VDC
● 20 VDC
● 15 VDC
● 9 VDC
● 5 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to 158°F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Battery
The following table lists the battery specifications of your Latitude 5430 Rugged.
Table 19. Battery specifications
Description Option one Option two
Battery type
3-cell, 53.5 Wh, lithium-ion,
ExpressCharge
3-cell, 53.5 Wh, lithium-ion, Long Life
Cycle
Battery voltage
11.4 VDC 11.4 VDC
Battery weight (maximum)
0.265 kg (0.584 lb) 0.265 kg (0.584 lb)
Battery dimensions:
Specifications of Latitude 5430 Rugged 19
