You can connect external displays directly to the Thunderbolt 4 (USB-C) ports, or up to four external displays using a USB-C
docking station and a direct connection to the Thunderbolt 4 (USB-C) port with a USB-C or Thunderbolt cable.
● Connect two external displays using direct USB-C or Thunderbolt cables:
● Connect up to four external displays:
NOTE:
○ Up to three displays can be connected to the USB-C docking station, and the additional display can be connected to
the right Thunderbolt 4 port with a USB-C or Thunderbolt cable.
○ The total number of external displays that is supported depends on the specifications of the USB-C docking station.
○ The maximum supported resolutions of the four external displays are as follows:
￭ 4K UHD (3840 x 2160), at 60 Hz refresh rate (For each of the three external displays that are connected to the
USB-C docking station)
- The following conditions are necessary:
• Each external display is connected to a DisplayPort connector on the USB-C docking station.
• Each external display must support Display Stream Compression (DSC).
￭ QHD (2560 x 1440), at 60 Hz refresh rate (For the external display that is connected to right Thunderbolt port
with a USB-C or Thunderbolt cable)
Connect external displays 9
