Dell P2421D User Manual

10 | Organizing Windows With Easy Arrange
Organizing Windows With Easy Arrange
On supported Dell monitors, the Easy Arrange tab enables you to easily arrange the
open windows in one of the predefined layouts by dragging them in the zones. Press
“>” or use Page Up/Page Down key to find more layouts. To create a custom layout,
arrange the open windows and then click Save.
To get started with Easy Arrange, choose a target monitor and select one of
the predefined layouts. The regions for that layout are displayed momentarily on
the monitor. Next, drag an open window across the monitor. While the window is
being dragged, the current window layout is displayed and an active region gets
highlighted as the window passes over it. At any time, drop the window into the
active region to place the window in that region.
Dell P2421D
To create a custom window layout, size and position the windows (maximum 10) on
the desktop and then click the Save link in Easy Arrange. The size and position of
the windows is saved as a custom layout and the custom layout icon is created.
NOTE: This option does not save or remember the applications that are
open. Only the size and position of the windows is saved.

Dell P2421D Specifications

General

3D	No
Pixel pitch	0.2058 x 0.2058 mm
Screen shape	Flat
Pixel density	123 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	23.8 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	49 - 75 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	29 - 113 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal	604.5 mm
Viewable size, vertical	296.35 mm
sRGB coverage (typical)	99 %
Display number of colors	16.78 million colors
Viewable size, horizontal	526.85 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1440
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
Doesn't contain	PVC
Sustainability certificates	RoHS, ENERGY STAR
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
On/off switch	-
Cables included	DisplayPort, USB
Input current	1.6 A
AC input voltage	120 - 230 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	55 W
Power consumption (standby)	0.2 W
Power consumption (typical)	16.9 W
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Market positioning	Business
Package depth	617.98 mm
Package width	165.1 mm
Package height	393.95 mm
Package weight	7290 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	5.4 mm
Bezel width (side)	5.5 mm
Height (with stand)	356.1 mm
Bezel width (bottom)	20.3 mm
Depth (without stand)	166 mm
Width (without stand)	537.8 mm
Height (without stand)	322.1 mm
Weight (without stand)	3370 g
