28 │ About your monitor
USB-C connector
Pin
number
Signal name
Pin
number
Signal name
A1 GND B1 GND
A2 TX1+ B2 TX2+
A3 TX1- B3 TX2-
A4 VBUS B4 VBUS
A5 CC1 B5 CC2
A6 D+ B6 D+
A7 D- B7 D-
A8 SBU1 B8 SBU1
A9 VBUS B9 VBUS
A10 RX2- B10 RX1-
A11 RX2+ B11 RX1+
A12 GND B12 GND
USB ports
• 1 USB-C upstream - bottom
• 4 SuperSpeed USB 5 Gbps (USB 3.2 Gen1) Type-A downstream - bottom
NOTE: SuperSpeed USB 5 Gbps (USB 3.2 Gen1) functionality requires
a SuperSpeed USB 5 Gbps (USB 3.2 Gen1)-capable computer.
NOTE: The USB ports on the monitor work only when the monitor is
turned On or in power save mode. If you turn Off the monitor and then
turn it On, the attached peripherals may take a few seconds to resume
normal functionality.
