Dell P2721Q Service Manual

Service Manual
5
2. Exploded view diagram with list of items
23
22
21
7B2203500-JRS-G
NAVIKEY BUTTON,FS,LE27SW,HF SLIDER,FS,LE27SW,HF
LIGHT BAR CABLE
2T581G900-HV7-G
SPRING,Φ0.5*D5*H17,HH,LE27SW,HF
2
1 1
KEYPAD METAL,L5,LE27SW,HF
1
1
EDP CABLE
1
1
LED CABLE
1B43PT500-600-G
P2721Q,MAIN CHASSIS,L5,LE27SW,HF
1B43PT300-600-G
2T54MN400-JRS-G
TAPE ADHENSIVE,L607W10T0.15,LE27SW
ASSY,BACK COVER,LGD,L5,LE27SW,HF
21B43PT400-600-G
STEEL PLATE,L5,LE27SW,HF
1
1
1
K-LOCK PLATE,SGCC,T0.5,L5,LE22SD
7010AP34QC00H01
Q't
Identification NO.
Designation
NO.
NO.
Designation
Q't
Identification NO.
26
ASSY,P2721Q,STAND,LE27SW,FFT,HF
28
27
RELEASE BUTTON,FS,LE27SW,HF
SIDE USB CABLE
LENS,FS,LE27SW,HF
FOIL,AL,DOUBLE COND,30*11mm*0.1mm
LED BOARD
FRONT BRACKET,L5,LE27SW,HF
1 1
1
1 1 1
1 1
1B51Y1E00-600-GFRONT TRIM,L5,LE27SW,HF
1
1
ASSY, FRONT TRIM,L5,LE27SW,HF 1
1B51Y1F00-600-G
MID FRAME,L5,LE27SW,HF
1
2
1B51Y1G00-600-GMID FRAME STATOR,L5,LE27SW,HF
1
SIDE USB BOARD
IF BOARD
1
POWER BOARD
24
7B2505N00-JRS-G 1
25
1
1A52LM500-600-G
2
3
1A52LM400-600-GASSY, FRONT TRIM,L5,LE27SW,HF
4
5
6
7 8 9
10
11
1
1A52LMA00-600-G
ASSY,P2721Q,MAIN CHASSIS,L5,LE27SW,HF
51115LP24H03R71
12 13 14 15 16 17
1A52LMA00-600-G
ASSY,P2721Q,MAIN CHASSIS,L5,LE27SW,HF
1A52LMC00-600-G
18 19 20
D52K6,REAR LOGO,BDG,PET,Circle,50mm
29
KEYPAD BOARD POWER BUTTON,FS,LE27SW,HF KEYPAD CABLE
1B43PT200-600-G
7B122BL00-JRS-G
7B122BM00-JRS-G
1B43KKR00-600-G 1B43KKR00-600-G 1A52LED00-80Q-G
1 1 1 1 1
1

Dell P2721Q Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Wall Mount	100mm x 100mm
Touch Screen	no
Webcam	no
OS Compatibility	windows, android, linux, chrome
Screen Size	26.96 inches
Panel Type	ips
Aspect Ratio	16:9
Resolution	3840 x 2160
Native Resolution	3840 x 2160
Refresh Rate	60hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	178 degrees
Response Time	5 milliseconds
Brightness	350 candela per square meter
Contrast Ratio	1000:1
Pixel Pitch	140 pixels per inch
Horizontal Scan Rate	135 kilohertz
HDR	no
Built-In Speakers	no
Display Port Inputs	1
Headphones Output	no
Power Consumption	35.6 watts
Depth with Stand	7.28 inches
Height with Stand	21.07 inches
Width with Stand	7.28 inches
Depth without Stand	2.1 inches
Height without Stand	14.2 inches
Net Weight without Stand	16 pounds
