Component Secured to Screw type Quantity Screw image
Hinge brackets Display back-cover and
antenna assembly
M2x2 2
I/O board Palm rest and keyboard
assembly
M2.5x2.5 2
Power-adapter port Palm rest and keyboard
assembly
M2x2 1
Power-button board Palm rest and keyboard
assembly
M2x2 1
Power button with
ngerprint reader
(optional)
Palm rest and keyboard
assembly
M2x2 1
Solid-state drive
NOTE: Applicable
for computers
shipped with M.2
SATA solid-state
drive.
Palm rest and keyboard
assembly
M2x3 1
System board Palm rest and keyboard
assembly
M2.5x2.5 3
Touchpad Touchpad and palm rest M2x2 4
Wireless-card bracket System board M2x3 1
