18 PowerConnect B-RX Series Getting Started Guide
53-1001682-03
FIGURE 8 Installing a module in a PowerConnect B-RX Series four-slot chassis
FIGURE 9 Installing a module in a PowerConnect B-RX Series eight-slot chassis
1Interface module
1 Management module
1
1
