8
Getting Started With Your System
Installing PowerConnect MPS600 or MPS1000 in a Rack
The PowerConnect MPS600 or MPS1000 can be installed in most standard
19-inch racks.
NOTE:
For racks that are not pre-threaded, cage nuts are provided.
Figure 1-6. Attaching Mounting Brackets–PowerConnect MPS600 or MPS1000
3
Use the screws that are provided to attach a mounting bracket to each side
of the
PowerConnect
MPS600 or MPS1000.
4
Position the
PowerConnect
MPS600 or MPS1000 in the rack and align the
holes in the mounting bracket with the holes in the rack.
5
Insert and tighten two screws through each of the mounting brackets.
