Intel® Server Platform SR870BH2 BIOS POST Error Codes and Messages
Revision 1.1
17
Error
Code
Error Message and Character
Attributes
Pause on
Boot
Failure
8508 Memory Mismatch detected
Row1. Row mapped out.
WARN/YELLOW_BLACK
Yes Issue with DIMM SPD value in Row 1; Row disabled,
Refer to “Memory” in Debug Methodology and failure
Isolation section.
8509 Memory Mismatch detected
Row2. Row mapped out.
WARN/YELLOW_BLACK
Yes Issue with DIMM SPD value in Row 2; Row disabled,
Refer to “Memory” in Debug Methodology and failure
Isolation section.
850C DIMM1 defective.
WARN/YELLOW_BLACK
Yes Issue with DIMM 1=J9J3, Refer to “Memory” in Debug
Methodology and failure Isolation section.
850D DIMM2 defective.
WARN/YELLOW_BLACK
Yes Issue with DIMM 2=J9J1, Refer to “Memory” in Debug
Methodology and failure Isolation section.
850E DIMM3 defective.
WARN/YELLOW_BLACK
Yes Issue with DIMM 3=J9D3, See memory in Debug
Methodology and failure Isolation section.
850F DIMM4 defective.
WARN/YELLOW_BLACK
Yes Issue with DIMM 4=J9D1, See memory in Debug
Methodology and failure Isolation section.
8510 DIMM5 defective.
WARN/YELLOW_BLACK
Yes Issue with DIMM 5=J9J2, See memory in Debug
Methodology and failure Isolation section.
8511 DIMM6 defective.
WARN/YELLOW_BLACK
Yes Issue with DIMM 6=J8J1, See memory in Debug
Methodology and failure Isolation section.
8512 DIMM7 defective.
WARN/YELLOW_BLACK
Yes Issue with DIMM 7=J9J2, See memory in Debug
Methodology and failure Isolation section.
8513 DIMM8 defective.
WARN/YELLOW_BLACK
Yes Issue with DIMM 8=J8D1, See memory in Debug
Methodology and failure Isolation section.
