Dell PowerEdge E10S - System Connectors, Video, and Power

Getting Started With Your System 9
Connectors
Back
NIC Two RJ-45 (for integrated 1-GB NICs)
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant
Video 15-pin VGA
eSATA One 7-pin connector
Front
Video 15-pin VGA
USB Two 4-pin, USB 2.0-compliant
Internal
USB Two 4-pin, USB 2.0-compliant
Video
Video type Matrox G200, integrated in Winbond WPCM450
Video memory 8 MB
Power
AC power supply (per power supply)
Wattage 250 W
Voltage 100-240 VAC, 50/60 Hz, 4-2 A
Heat dissipation 1039 BTU/hr maximum
Maximum inrush current Under typical line conditions and over the entire
system ambient operating range, the inrush
current may reach 25 A
Batteries
System battery CR 2032 3.0-V lithium ion coin cell
