Cabling Your Blade Cluster Hardware 31
Figure 2-2. Direct-Attached Cluster Configuration Using CX3-10c Storage System
1 Ethernet pass-through module 2 7 iSCSI ports
2 port 5 8 port 4
3 port 4 9 port 5
4 SP-B 10 Ethernet pass-through module 1
5 SP-A 11 internal connections
6 Fibre Channel ports
2 Fibre 2 Fibre
0 iSCSI 0 iSCSI1 iSCSI 1 iSCSI
3 Fibre 3 Fibre
9
7
53
1
1086
42
public network
3
8
PowerEdge server enclosure
1
10
9
2
11
4
5
iSCSI
connection
CX3-10c storage system
management
connection
6
7
