Back View
WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow
environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer
turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.
12
11
9
4
3
1
1 modem connector (optional)
2 network connector
3 power and battery status lights
4 video connector (VGA)
5 AC adapter connector
6 security cable slot
7 eSATA/USB 2.0 connector
8 USB 2.0 connector
9 multimode DisplayPort connector
10 cooling vent
11 ExpressCard slot
12 Secure Digital (SD) and MMC card slot
10
2
5
6
7
8
