Dell Precision M4500 Setup & Features

Specifications
NOTE: Offerings may vary by region. For more information regarding
the configuration of your computer, click Start→ Help and Support
and select the option to view information about your computer.
System Information
Processor type Intel
®
i5 and i7 Dual Core
Intel Core i7 Quad Extreme
Intel Core i7 Quad
Chipset Mobile Intel 5 series chipset (QM57)
Video
Video type Discrete
Data bus
• PCI-E x16 Gen1
• PCI-E x16 Gen2
Video controller NVIDIA Quadro FX 880M
NVIDIA Quadro FX 1800M
Memory
Type DDR3, 1066 MHz / 1333 MHz
Memory module
connector
two SODIMM slots
Memory module capacity 1 GB or 4 GB
Minimum memory 2 GB
Maximum memory 8 GB
Contactless Smart Card
Supported Smart Cards
and Technologies
ISO14443A — 106 kbps, 212 kbps, 424 kbps,
and 848 kbps
ISO14443B — 106 kbps, 212 kbps, 424 kbps,
and 848 kbps
ISO15693
HID iClass
FIPS201
NXP Desfire
Battery
Type 6-cell "smart" lithium ion (60 WHr)
9-cell "smart" lithium ion (81 WHr)
9-cell "smart" lithium ion (90 WHr)
Dimensions
6-cell
Depth
206.00 mm (8.11 inches)
Height 19.80 mm (0.78 inch)
Width 47.00 mm (1.85 inches)
9-cell
Depth
208.00 mm (8.18 inches)
Height 22.30 mm (0.87 inch)
Width 69.00 mm (2.71 inches)
Weight
6-cell 329.00 g (0.72 lb)
9-cell 485.00 g (1.07 lb)
Voltage 11.10 V
PHRV5am0.fm Page 4 Tuesday, February 16, 2010 4:24 PM

Dell Precision M4500 Specifications

General

Processor	Intel Core i5 or i7
Graphics	NVIDIA Quadro FX 880M or 1800M
Memory	Up to 16GB DDR3
Storage	Up to 500GB HDD or 256GB SSD
Operating System	Windows 7 Professional
Networking	Gigabit Ethernet
Battery	6-cell or 9-cell Lithium Ion
Display	15.6 inch
Weight	2.72 kg (6 lbs)
Chipset	Intel QM57
Resolution	Up to 1920x1080 (Full HD)
Optical Drive	DVD+/-RW
Wireless	Wi-Fi 802.11a/g/n
Ports	USB 2.0, eSATA, DisplayPort, VGA
