Dell Precision M4500 Setup & Features

Temperature range
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 60 °C (–40 °F to 140 °F)
Coin-cell battery 3 V CR2032 lithium coin cell
AC Adapter
Input voltage 100 V–240 V ~
Input current (maximum) 1.50 A or 2.50 A
Input frequency 50 Hz–60 Hz
Output power 130 W
Output current 6.70 A (maximum at 4-second pulse)
Rated output voltage 19.50 VDC
Dimensions
Depth 25.40 mm (1.00 inch)
Height 76.20 mm (2.99 inches)
Width 154.70 mm (6.09 inches)
Temperature range
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °C to 149 °F)
Battery (continued) Physical
Depth 253.30 mm (9.97 inches)
Height 27.60 mm (1.08 inches)
Width 374.30 mm (14.73 inches)
Weight
(minimum) 2.81 kg (6.20 lb)
Docking Connector
E-Family dock 144–pin docking connector
Environmental
Temperature range
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative humidity
(maximum)
Operating 10% to 90% (noncondensing)
Storage 5% to 95% (noncondensing)
Altitude (maximum)
Operating –15.20 m to 3048 m (–50 ft to 10,000 ft)
Storage –15.20 m to 10,668 m (–50 ft to 35,000 ft)
PHRV5am0.fm Page 5 Tuesday, February 16, 2010 4:24 PM

Dell Precision M4500 Specifications

General

Processor	Intel Core i5 or i7
Graphics	NVIDIA Quadro FX 880M or 1800M
Memory	Up to 16GB DDR3
Storage	Up to 500GB HDD or 256GB SSD
Operating System	Windows 7 Professional
Networking	Gigabit Ethernet
Battery	6-cell or 9-cell Lithium Ion
Display	15.6 inch
Weight	2.72 kg (6 lbs)
Chipset	Intel QM57
Resolution	Up to 1920x1080 (Full HD)
Optical Drive	DVD+/-RW
Wireless	Wi-Fi 802.11a/g/n
Ports	USB 2.0, eSATA, DisplayPort, VGA
