Dell Precision R7610 Manual

Power
Coin-cell battery 3 V CR2032 lithium coin cell
Voltage 100 V to 240 V, 12.00 A to 6.00 A, 50 Hz to 60 Hz
Wattage
• 1023 W : 100 VAC to 120 VAC,
• 1100 W : 200 VAC to 240 VAC
• 1400 W : 200 VAC to 240 VAC
Maximum heat dissipation 4774 BTU/hr
NOTE: Heat dissipation is calculated by using the power supply wattage rating.
Physical
Height 86.30 mm (3.40 inches)
Width 440.60 mm (17.35 inches)
Depth
792.70 mm (31.21 inches) with front bezel
753.60 mm (29.67 inches) without front bezel
Weight (Minimum) 19.32 kg (42.60 lb)
Environmental
Operating Temperature 0 °C to 35 °C (32 °F to 95 °F)
Information para NOM (únicamente para México)
The following information is provided on the device described in this document in compliance with the requirements of
the official Mexican standards (NOM).
Voltaje de alimentación
• 1100 W : 200 V CA – 240 V CA
• 1023 W : 100 V CA – 120 V CA
• 1400 W : 200 V CA – 240 V CA
Frecuencia 50 Hz – 60 Hz
Intensidad de salida 6.7 A /12 A
Finding More Information and Resources
See the safety and regulatory documents that shipped with your computer and the regulatory compliance website at
www.dell.com/regulatory_compliance for more information on:
• Safety best practices
• Regulatory certification
4

Dell Precision R7610 Specifications

General

Tcase	86 °C
Bus type	QPI
FSB Parity	No
Processor cache	30 MB
Processor cores	12
Processor model	E5-2697V2
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v2
Processor socket	LGA 2011 (Socket R)
Processor threads	24
Processor codename	Ivy Bridge EP
Number of QPI links	2
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Thermal Design Power (TDP)	130 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800, 1066, 1333, 1600, 1866 MHz
Memory bandwidth supported by processor (max)	59.7 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	8x DIMM
Internal memory	32 GB
Memory channels	Quad-channel
Memory clock speed	1600 MHz
Maximum internal memory	128 GB
Storage media	HDD
Optical drive type	-
Total storage capacity	500 GB
Discrete graphics card model	NVIDIA® Quadro® NVS 310
On-board graphics card model	Not available
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Headphone outputs	0
USB 2.0 ports quantity	6
PCI Express x16 slots	4
Chassis type	Rack-mounted chassis
Product color	Black, Silver
Rack capacity	2U
Placement supported	Horizontal
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C602
Password protection type	BIOS
Sustainability certificates	RoHS
Certification	WEEE
Scalability	2S
Processor ARK ID	75283
Processor package size	52.5 x 51 mm
Supported instruction sets	AVX
Physical Address Extension (PAE)	46 bit
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	753.6 mm
Width	440.6 mm
Height	86.3 mm
Weight	- g
