Dell Precision T3500 - Back Panel Connectors

Back Panel Connectors
1 parallel connector 2 PS/2 mouse connector
3 line-out connector 4 link integrity light
5 network adapter connector 6 network activity light
7 USB 2.0 connectors (2) 8 line-in connector
9 eSATA connector 10 USB 2.0 connectors (4)
11 PS/2 keyboard connector 12 serial connector
