Network link light
green light — Solid green indicates connection to an
active network
off (no light) — System is not connected to a network
Rear of the computer:
Link integrity light (on
integrated network adapter)
link integrity light color is based on the link speed:
green light — A good connection at 10Mbs exists between
the network and the computer.
orange light — A good connection at 100Mbs exists between
the network and the computer.
yellow light — A good connection at 1000Mbs exists
between the network and the computer.
off(no light) — The computer is not detecting a physical
connection to the network.
Network activity light (on
integrated network adapter)
yellow blinking light
Power
DC power supply:
Voltage (see the safety
information that shipped
with your computer for
important voltage setting
information)
115/230 VAC, 50/60 Hz, 6.0/3.0 A
Coin-cell battery
3 V CR2032 lithium coin cell
Physical
Height 44.8 cm (17.6 inches)
Width 17.25 cm (6.8 inches)
Depth 46.8 cm (18.4 inches)
Weight 17.3 kg (38.0 lb)
Controls and Lights (continued)
J017Mam1.fm Page 7 Thursday, June 11, 2009 5:30 PM

Other manuals for Dell Precision T3500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell Precision T3500 and is the answer not in the manual?

Dell Precision T3500 Specifications

General IconGeneral
Tcase67.9 °C
Bus typeQPI
SteppingD0
FSB ParityNo
Processor cache8 MB
Processor cores4
Processor modelW3550
System bus rate4.8 GT/s
Processor seriesIntel Xeon 3500 Series
Processor socketSocket B (LGA 1366)
Processor threads8
Processor codenameBloomfield
Processing Die size263 mm²
Processor frequency3.06 GHz
Processor cache typeSmart Cache
Processor lithography45 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.33 GHz
Processor operating modes64-bit
ECC supported by processorYes
Thermal Design Power (TDP)130 W
Processor core voltage (AC)1.225 V
Number of processors installed1
CPU multiplier (bus/core ratio)23
Memory types supported by processorDDR3-SDRAM
Number of Processing Die Transistors731 M
Memory clock speeds supported by processor800, 1066 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor24 GB
DisplayLCD
Graphics cardFirePro V5900
Dimensions (WxDxH)172 x 468 x 447 mm
Networking featuresGigabit Ethernet (10/100/1000)
Graphics card manufacturerAMD
Audio systemHD
Product typeWorkstation
Motherboard chipsetIntel® X58 Express
Memory slots-
Internal memory4 GB
Memory channelsTriple-channel
Memory clock speed1333 MHz
Memory layout (slots x size)2 x 2 GB
HDD speed7200 RPM
HDD capacity500 GB
HDD interfaceSATA III
Optical drive typeDVD Super Multi DL
Maximum graphics card memory2.048 GB
Display diagonal22 \
Display number of colors16.78 million colors
PS/2 ports quantity2
USB 2.0 ports quantity11
VGA (D-Sub) ports quantity0
Chassis typeTower
Product colorBlack, Silver
Cable lock slot typeKensington
Number of 3.5\" bays3
Operating system installedWindows XP Professional
Compatible operating systemsWindows 7
Power supply525 W
Processor ARK ID39720
Processor package size42.5 x 45.0 mm
Supported instruction setsSSE4.2
Intel® Turbo Boost Technology1.0
Weight and Dimensions IconWeight and Dimensions
Depth468 mm
Width172 mm
Height447 mm
Weight17700 g
