Specifications 47
Power Supply Universal AC 100-240 V 50-60 Hz with PFC
input
Power Consumption Normal mode: 230 W ± 10% @ 110 Vac
Eco mode: 195 W ± 10% @ 110 Vac
Standby mode: < 0.5 W
Audio 1 speaker x 2 watt RMS
Noise Level Normal mode: 34 dB(A)
Eco mode: 31 dB(A)
Projector Weight 5.4 lbs (2.4 kg)
Dimensions (W x H x D) 12.38 x 3.45 x 8.8 inches (314.4 x 87.6 x 223.5
mm)
Environmental Operating temperature: 5 °C - 40 °C (41 °F-
104 °F)
Humidity: 80% maximum
St
orage temperature: 0 °C to 60 °C
(32 °F to 140 °F)
Humidity: 90% maximum
Shipping temperature: -20 °C to 60 °C
(-4 °F to 140 °F)
Humidity: 90% maximum
I/O Connectors Power: One AC power socket (3-pin - C14
inlet)
VGA input: One 15-pin D-sub connector (Blue),
VGA In, for analog RGB/Component input
signals.
3.45"(87.6 mm)
12.38"(314.4 mm)
8.8"(223.5 mm)
