23" LCD Color Monitor Dell SP2309Wc
10
Back
Press
to go back to the main menu.
Brightness
Allows you to adjust the brightness or luminance of the backlight.
Press the
button to increase brightness and press the button to
decrease brightness (min 0 ~ max 100).
Contrast
Allows you to adjust the contrast or the degree of difference between
darkness and lightness on the monitor screen. Adjust brightness first, and
adjust contrast only if you need further adjustment.
Press the
button to increase contrast and press the button
to decrease contrast (min 0 ~ max 100).
Auto Adjust
Use this button to activate automatic setup and adjust menu. The following dialog
appears on a black screen as the monitor self-adjusts to the current input:
Auto Adjustment allows the monitor to self-adjust to the incoming video signal.
After using Auto Adjustment, you can further tune your monitor by using the Pixel
Clock (Coarse) and Phase (Fine) controls under Image Settings.
Input Source
Use the Input Source menu to select different video signals that may be connected
to your monitor.
To Next Page
