23" LCD Color Monitor Dell SP2309Wc
55
White screen
White screen
Measure Q705 base
is high level?
X401 oscillate
waveform is normal
Check Q704, Q705, Q701
is broken or CN403 solder?
Check Correspondent
component.
Replace PANEL
Check Correspondent
component.
Replace U401
OK
OK
OK
Replace X401
OK
NG
NG
NG
NG
Check reset circuit of
U401 is normal
