Dell ST2210B - Flat Panel Specifications

HDMI Connector

Flat Panel Specifications
13
Floating
14
+5V power
15
Selftest
16
Hot Plug Detect
17
TMDS RX0-
18
TMDS RX0+
19
TMDS Ground
20
Floating
21
Floating
22
TMDS Ground
23
TMDS Clock+
24
TMDS Clock-
Pin Number
19-pin Side of the Connected Signal Cable
1
TMDS DATA 2+
2
TMDS DATA 2 SHIELD
3
TMDS DATA 2-
4
TMDS DATA 1+
5
TMDS DATA 1 SHIELD
6
TMDS DATA 1-
7
TMDS DATA 0+
8
TMDS DATA 0 SHIELD
9
TMDS DATA 0-
10
TMDS CLOCK
11
TMDS CLOCK SHIELD
12
TMDS CLOCK-
13
CEC
14
Reserved (N.C. on device)
15
DDC CLOCK (SCL)
16
DDC DATA (SDA)
17
DDC/CEC Ground
18
+5V POWER
19
HOT PLUG DETECT
Model
ST2210B
ST2310B
Screen type
Active matrix - TFT LCD
Active matrix - TFT LCD
Panel type
TN
TN
Screen dimensions
21.5 inches (21.5-inch viewable image size)
23 inches (23-inch viewable image size)
Preset display area:
Horizontal
Vertical

476.64 mm (18.76 inches)
268.11 mm (10.56 inches)

509.18 mm (20.05 inches)
286.41 mm (11.28 inches)
Pixel pitch
0.248 mm
0.266 mm
Viewing angle
160°(vertical)typical,160°(horizontal)typical
160°(vertical)typical,160°(horizontal)typical
Luminance output
250 CD/m ²(typical)
250 CD/m ²(typical)
