Using Your Studio XPS™ 435MT
Back Panel Connectors
1
IEEE 1394 connector — Connects to
high-speed serial multimedia devices such
as digital video cameras.
2
Network connector and light —
Connects your computer to a network
or broadband device. The network
activity light flashes when the computer
is transmitting or receiving data. A high
volume of network traffic may make this
light appear to be in a steady “on” state.
3
Back L/R surround connector —
Connects to multichannel capable
speakers.
4
Center/subwoofer connector —
Connects to a subwoofer.
1
2
3
4
5
6
7
8
9
10
