Dell Studio XPS 435MT - Page 51

49
Specications
System Board Connectors
Chassis fan one 3-pin connector
Front panel audio
HDA header
one 10-pin connector
Front panel control one 10-pin connector
Internal USB device four 10-pin connectors
Memory six 240-pin connectors
PCI Express x1 three 36-pin
connectors
PCI Express x16 one 164-pin connector
Power one 24-pin connector
Power 12 V one 8-pin connector
Processor 1366 pins
System Board Connectors
Processor fan one 4-pin connector
Serial ATA four 7-pin connectors
S/PDIF out one 6-pin connector
Front IEEE 1394
header
one 10-pin connector
Physical
Height 36.2 cm (14.2 inches)
Width 17.0 cm (6.7 inches)
Depth 43.5 cm (17.1 inches)
Weight 7.45 kgs
