10 | About Your Monitor
Monitor Specifications
Screen type Active matrix - TFT LCD
Panel Type In-plane switching Technology
Aspect ratio 16:9
Viewable image dimensions
Diagonal 68.47 cm (27 in.)
Active Area
Horizontal
596.74 mm (23.49 in.)
Vertical 335.66 mm (13.21 in.)
Area 200301.7 mm
2
(310.47 in.
2
)
Pixel pitch 0.1554 mm x 0.1554 mm
Pixel per inch (PPI) 163
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness 350 cd/m² (typical)
Contrast ratio 1300 to 1 (typical)
Display screen coating Anti-glare treatment of the front polarizer (3H) hard
coating
Backlight LED
Response Time (Gray to Gray) 5 ms (FAST mode)
8 ms (NORMAL mode)
Color depth 1.07 billion colors
Color gamut* 99% sRGB
99% REC709
95% DCI-P3
Calibration accuracy Delta E < 2 (average)
Connectivity •1 x DP 1.4 (HDCP 1.4/HDCP 2.2)
•1 x HDMI 2.0 (HDCP 1.4/HDCP 2.2)
•1 x USB Type-C (Alternate mode with DisplayPort 1.4,
USB 3.0 upstream port, Power Delivery PD up to 90 W)
•2 x USB 3.0 downstream port
•1 x USB 3.0 downstream port with BC1.2 charging
capability at 2 A (max)
•1 x Analog 2.0 audio line out (3.5 mm jack)
•1 x USB 3.0 Type-C downstream port with charging
capability at 3 A (max)
