Multimedia Card Reader
Dell™Vostro™230ServiceManual—Mini Tower
Removing the Multimedia Card Reader
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the front bezel.
4. Disconnect the data cable connector from the system board.
5. Remove the screws that secure the multimedia card-reader assembly to the computer.
6. Remove the multimedia card reader from the computer by sliding it through the front of the computer.
Replacing the Multimedia Card Reader
To replace the multimedia card reader, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
