Dell Vostro 2421 - Installing the Display Panel

Installing the Display Panel
1. Connect the display cable to display panel.
2. Affix the tape to secure the display cable.
3. Place the display panel on the computer.
4. Tighten the screws to secure the display panel to the computer.
5. Install:
a) display bezel
b) display assembly
c) palmrest
d) keyboard
e) optical-drive assembly
f) hard-drive assembly
g) memory module
h) access panel
i) battery
6. Follow the procedures in After Working Inside Your Computer .
Removing the Display Hinges
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a) battery
b) access panel
c) memory module
