Technical Overview
Dell™ XPS™ 430 Service Manual
Inside View of Your Computer
System Board Components
CAUTION: Before working inside your computer, read the safety information that shipped with your
computer. For additional safety best practices information, see the Regulatory Compliance Homepage at
www.dell.com/regulatory_compliance.
Inside View of Your Computer
1 power supply 2 system board 3 hard drive (2)
4 card fan 5 processor fan 6 processor airflow shroud
System Board Components
