DeLonghi AM9P022DT-P00F - PARTS AND ASSEMBLY

6
PARTS & ASSEMBLY
A
A. Control panel
Turntable roller
Glass turntable
Door with viewing panel
Seal
Interlocking catches
Waveguide cover
Ensure all packaging materials, protective film and adhesive tape are
removed and check the oven and door for any damage. Do not
remove the waveguide cover.
Assemble as shown above and ensure that the glass turntable is
correctly positioned on the roller.


B
C
D
E
F
G
B.
C.
D.
E.
F.
G.
