DeLonghi CF08E - Description

- 3 -
Drainage Tank
Handle
Air Outlet
Louvre
Control Panel
Refer to next page
Sensor
Do not obstruct!
Float
Guard
Water Level
Gauge
When the unit is purchased,
there may be some water left in
the drainage tank. This is from
the dehumidifying test
conducted at the factory, and
does not indicate a problem.
Back panel
Continuous
Drainage Port
Refer to page 7
Air Filter
(Back panel air inlet)
do not obstruct!
Refer to page 8
Cord Hook
Cord Band
(undo on operation)
Power Supply Plug
Castors
Refer to page 7
Description
Front panel
