26
HED-HCAT SE FREE COOLING
ENGLISH
Click on the scrolling selectors to display the current sta-
tus of the machine
Click on the parameters menu to access the following sub-
menus:
To enter the Maintenance Man menu:
-Using the scrolling selectors position on MAINTE-
NANCE MAN and click the enter key
Parameters menu
Work Mode
Cooling Heating
Dehumid.
Work Mode
Supply air limit
Dehumid.limit
MAINTENANCE MAN
Printer
Inputs/Outputs
Clock
Setpoint
User
MANUFACTURER
Display page with the software version,date and language
Shelter De’Longhi
Ver.: _ _ / _ _ / _ _
Language: English
Display page with the bios, Boot, Manual and software ver-
sion
Bios: _ :_ _ _ _ / _ _ / _ _
Boot: _ :_ _ _ _ / _ _ / _ _
Manual: _ _ _ _ _ _ _ _ _ __ _ _
Ver.: _ : _ _ _ _ / _ _ / _ _
Display page with the hours of operation of the main fan
Running Hours:
Main Fan 00.000h
Display page with the hours of operation of compressor 1
Running Hours:
Compressor 1 00.000h
If active it becomes
CONTROL AND DISPLAY PARAMETERS
A0
M1
_ _ _ _ _ _ _ _ _ _ /_ _ _/_ _ _ _
Temperature _ _ _ _ _ _ _ _ _ °C
Humidity _ _ _ _ _ _ _ _ _ _ _ %
Off Alarm U:00
M0
M2
A1
A2
A3
STATUS SCREEN
