5. Remove the stopper and lower door stop
block from the bottom of the lower door
and move them to the opposite side. Screw
tightly.
6. Remove both levelling feet, levelling feet fix
board and bottom hinge.
7. Swap the position of the levelling feet fix
board with the bottom hinge. On the bottom
hinge, move the position of the bottom
hinge pin to the other hole. Tighten the pin
securely.
8. Screw the levelling feet fix board, bottom
hinge and levelling feet tightly on their new
position.
9. Remove the middle hinge hole covers and
swap their position with the middle hinge.
Reverse the middle hinge.
• DO NOT lay the unit flat as this may
damage the coolant system.
• During door reversal, when swapping
the position of the bottom hinge or
adjusting the levelling feet, tilt the unit.
Do not lay the unit flat.
