CONTROL PANEL
10. Right semi-rapid burner control knob (1)
11. Rapid burner control knob (2)
12. Triple-ring burner control knob (3)
13. Left semi-rapid burner control knob (4)
14. Auxiliary burner control knob (5)
■ This appliance is class 3 rated
■ The appliance has a safety valve system fitted (beside every burner there is the “T”
probe as in fig. 16 - not confuse with the “S” electrode of the electronic ignition) the
flow of the gas will stopped if and when the flame should accidentally go out.
■ The cooktop is provided with electric gas-lighting device, beside flame - maxi-
mum aperture or max gas flow - there is the
★ symbol).
GAS BURNERS Natural Gas Universal LPG
MJ/h MJ/h
1. Right semi-rapid burner (SR) 6.30 6.30
2. Rapid burner (R) 10.30 10.80
3. Central triple ring burner (TR) 13.00 11.90
4. Left semi-rapid burner (SR) 6.30 6.30
5. Auxiliary burner (A) 3.60 3.60
