7
Figure 4a Fig. 4b Figure 4c Fig. 4d
Figure 4e
APPLYING THE SEALS
(Refer to Figures 4):
– Turn the cooker top upside down.
– Spread the longer seal “A” around the
left, rear and right sides as shown in
figure 4a.
– With a cutter or a scissors cut the
excess seal “C” and retain it for next
use (figure 4b)
FRONT
seal A
seal C
seal A
seal C seal B
seal C
seal B
– Spread the seal “B” around the left,
front and right edges of the cooker
top as shown in figure 4c.
– Spread the seal “C” along the rear
edge of the cooker top as shown in
figure 4d. Making sure that the begin-
ning and the end overlap at the seal
“B” (see figure 4e).
