DeLonghi DSC 95 E - Stability Bracket

34
Wall fixing
Floor fixing
Dimension is in millimetres
3
Outline of cooker
backplate at the
engagement slot
Fig. 8.8
We recommend a stability bracket is fitted to the cooker.
The type shown in fig. 8.8 can be purchased from most plumbers merchants and
do it yourself (D.I.Y.) shops.
Bracket
Existing slot in
rear of cooker
Dotted line showing the
position of cooker when fixed
Stability bracket
