Doc. Nr.: DSDL_23016_A
[18]
7.3. COFFEE TEMPERATURE TEST
Complains from end users about coffee temperature are quite frequent. They are mainly due to incorrect
appliance adjustments or to an incorrect expectation by the customer.
A coffee temperature measurement is required all the times any of these complaints are encountered.
To perform the coffee temperature test, follow in sequence the below steps:
Turn the appliance ON.
Set the temperature to MAX level.
Run 1-2 rinse cycles, to warm up the hydraulic circuit.
Select to prepare an X2 ESPRESSO COFFEE (2 cups recipe, refer to the user manual for more details).
Start the coffee preparation.
Wait until at least 20ml of coffee have been delivered into the cup.
Measure the coffee flow temperature at about 2÷10mm from the coffee spout, as shown in the
below picture:
The optimal indicative temperature measurement for coffee should be 83°C±3°C.
