Heating and Air Conditioning
rw^i
dial-a-charge
to bulk gas
white
hose
blue hose
k
red hose
to vacuum pump
*0.
27
rf^i
(V'-^l
This is the basic equipment required to check and
service the air conditioning unit on De Lorean
Motor Company cars.
The Service Station (95301) allows the service
technician to diagnose any faults on the
refrigeration side of the system, also to evacuate
and dehydrate and recharge the
R -12
into the
system without disconnecting, i.e. allowing air and
moisture into the system. (Note: safety
precautions when handling
R-12
Fig. 27
—
28.)
Note:
Reference to colour coded hoses may only apply to
DMC Service Tool No.
95301.
Extreme caution to be observed that correct
connections are made.
VACUUM GAUGE
Fig. 28
MANIFOLD
•BLUE
^jP«t
