Connection Systems
Delphi Connections Systems Page 5 of 11 01/02/2001
Note: Assembly Instructions are provided for reference only, and are intended for use by skilled assembly technicians.
Personal injury, failure of the system to work as intended, and damage to the product may result from failure to follow the
assembly and disassembly techniques and/or use of tools other than those described. Always follow Assembly
Instructions thoroughly, and please contact Delphi Connection Systems for further assistance.
RECOMMENDED PLUGGING SEQUENCE
32
48
64
17
33
49
Plugging should be from right to left and from
bottom to top, for best visibility, access in plugging.
PLUG
DIRECTION:
RIGHT TO LEFT,
BOTTOM TO TOP.
Horizontal Holder
This is not a recommended holder position,
because the wire dress would be upward, and the
leads would be very difficult to route.
1 17 33 49
16 32 48 64
Vertical Holder
To Next Page
