Delphi MICRO 64 User Manual

Connection Systems
Delphi Connections Systems Page 6 of 11 01/02/2001
Note: Assembly Instructions are provided for reference only, and are intended for use by skilled assembly technicians.
Personal injury, failure of the system to work as intended, and damage to the product may result from failure to follow the
assembly and disassembly techniques and/or use of tools other than those described. Always follow Assembly
Instructions thoroughly, and please contact Delphi Connection Systems for further assistance.
ASSEMBLY INSTRUCTIONS
MICRO 64 CONNECTOR ASSEMBLY
ROUTING OF LEADS:
PROPER ROUTING OF LEADS ON
THE BUILD FIXTURE IS CRITICAL. WHILE ROUTING
LEADS AFTER PLUGGING MICRO 64 TERMINALS,
ASSEMBLY OPERATORS SHOULD APPLY ONLY LIGHT
FORCE BECAUSE LEADS COULD BE PULLED OUT OF
THEIR CAVITIES.
STEP 3:
APPLY SECONDARY LOCK:
AFTER PLUGGING ALL
THE LEADS INTO THE CONNECTOR BODY, START
SECONDARY LOCK INTO CONNECTOR AND PUSH TO
INSERT. ORIENTATION IS REQUIRED.
USE TOOL # 12152222 TO FULLY SEAT THE
SECONDARY LOCK TO A HARD STOP POSITION.
CAUTION: THE SECONDARY LOCK MUST BE FULLY
SEATED,
BEFORE REMOVING THE CONNECTOR BODY
FROM ITS HOLDER OR APPLYING ANY COVERINGS.
STEP 4:
APPLY HARNESS COVERINGS PER PRODUCT PRINT.
STEP 5:
BUILD (1) ONE COVER TO CONNECTOR ASSEMBLY.
A. APPLY WIRE DRESS C
OVER TO CONNECTOR BY
INSERTING FLEX LEGS INTO LOCK SLOTS AT
LEVER END.
B. INSERT STATIONARY TABS OF WIRE DRESS
COVER INTO SLOTS IN CONNECTOR NEAR
WIRE EXIT.
STEP 6:
APPLY NOSE-PIECE TO CONNECTOR ASSEMBLY. STEP 7:
