Contacting Product Technical Support and
Customer Service
If problems persist after trying all of these trouble-
shooting steps, unplug the A/C power adaptor and
remove all batteries. Wait until the CD panel or
SKYFi Receiver display clears completely, then plug
the A/C power adaptor back in and re-insert batter-
ies. If this does not fix the problem, contact Delphi
at 1.877.GO DELPHI (1.877.463.3574) Monday
through Friday.
TECHNICAL INFORMATION
Audio Power Specifications
Power Output and Harmonic Distortion
With 3.2-ohm loads, both channels are driven from
150 to 10,000 Hz; rated 2.3 W per channel—minimum
RMS power, with no more than 10 percent total
harmonic distortion in A/C operation.
Other Specifications
CD/MP3 Player
System Compact disc digital audio
system
Laser diode properties
Material GaAlAs
Wavelength 780 nm
Emission duration Continuous
Laser output
(1)
<44.6 mW
Spindle speed 200 rpm to 500 rpm (CLV)
Number of channels 2
Frequency response 70 Hz – 20 kHz +1/-3 dB
Wow and flutter Below measurable limit
(1) Value measured at ~200 mm from the objective lens surface on the
optical pickup block with a 7 mm aperture.
AM/FM Radio
Frequency range
AM 530 – 1710 kHz
FM 87.5 – 107.9 MHz
Antenna AM internal
FM telescoping
General
Speakers Full range: 10 cm (4 in.)
diameter, 3.2 W, cone type (2)
Outputs 3.5 mm diameter ministereo
jack
Power output 2.3 W + 2.3 W (at 3.2 W,
10 percent harmonic distortion)
Power requirements
Delphi CD Audio System
D/C IN 12V jack Accepts supplied A/C power
adaptor for use with 120 V A/C,
60 Hz
Battery operation Accepts 6 D-size (R20) batteries
(not included)
Remote control Requires 2 AAA-size batteries
(included)
Dimensions
Delphi CD Audio System 20 in. W x 10 in. H x 7.5 in. D
(50.8 cm x 25.4 cm x 19.1 cm)
Remote control 4-5/8 in. W x 1-5/8 in. H x 1 in. D
(117 mm x 40.5 mm x 25 mm)
Weight
Delphi CD Audio System 5 lbs. 13 oz. (2.64 kg)
FM antenna 7.8 oz. (.22 kg)
Remote control 2.1 oz. (.06 kg)
Construction Body made of durable,
ABS plastic; handle has
thermoplastic rubber
(TPR) insert for easy grip
Liquid crystal display 40 mm x 20 mm dot
(LCD) matrix with orange LED
backlighting
Supplied accessories 12V A/C power adaptor
Integrated remote control
High-gain satellite radio
antenna
14
SECT ION 4
• Technical Support: 8 a.m. to 5:00 p.m. Eastern
Standard Time
