Delta Children Close2Me - Bassinet Frame Assembly; Frame Component Connections

7
Customer Service gcs@DeltaChildren.com www.DeltaChildren.com
Bassinet Frame Assembly
NOTE: You may need the help of another adult to help steady all parts for
assembly.
• Slide the side frame into the Main Frame until you hear an audible
“CLICK!” (Fig. 1)
• Slide the cover over the exposed parts of the side frame (Fig. 2).
• Put the material on the tube of the main frame and close the zipper
(Fig. 3).
• Connect the tube of the drop-side with the upper part of the frame (Fig.
4).
1
4
2
3
Fig. 1
Fig. 3
Fig. 2
Side Frame
Main Frame
Fig. 4
