8
Customer Service gcs@DeltaChildren.com www.DeltaChildren.com
• Close zipper over the drop-down bar by pulling from the inside of the
bassinet around the top and down the outside (Fig. 5).
• Attach the side support to the middle support as seen in (Fig. 7)
• Push the side support onto the middle support until you hear an audible
“CLICK!” on both sides.
• Take the piece made above in step 7. With the bent section of the
Side Support facing upwards, insert the combined piece into the plastic
housings found on the frame legs until you hear an audible “CLICK!” on
both sides. (Fig. 8)
• Lay the bassinet down with bottom facing you. (Fig. 6).
• Insert the cross bar into one of the frame legs until you hear an audible
“CLICK!”
• Repeat on opposite frame leg.
• Replace frame in upright position
5
6
7
8
Bassinet Frame Assembly
Fig. 5
Fig. 6
Cross Bar
Fig. 7
9
Middle Support
Side Support
Fig. 8
To Next Page
