Delta Electronics AC Motor Drive VFD007S23A

Appendix B Accessories|VFD-S Series
Revision August 2006, SE08, SW V2.61 B-15
B.4 DC Choke Recommended Values
230V DC Choke
Input voltage kW HP DC Amps Inductance (mh) MTE CAT. NO
0.2 1/4
2 20.00 2RB003
0.4 1/2
4 15.00 4RB003
0.75 1 9 7.50 9RB003
1.5 2 12 4.00 12RB003
230Vac
50/60Hz
3-Phase
2.2 3 18 2.75 18RB003
0.2 1/4 4 50.00 --
0.4 1/2 9 25.00 --
0.75 1 9 12.00 --
1.5 2 12 8.00 --
230Vac
50/60Hz
1-Phase
2.2 3 18 6.00 --
460V DC Choke
Input voltage kW HP DC Amps Inductance (mh) MTE CAT. NO
0.4 1/2 2 50.00 2RB004
0.75 1 4 25.00 4RB004
1.5 2 9 11.50 9RB004
460Vac
50/60Hz
3-Phase
2.2 3 9 11.50 9RB004
