Delta Temperature Controller User Manual
2007-09-17 - 12 - © DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
Display Explanations
PV SV Status of the temperature controller
Message displayed when DTA has not yet been connected
to a sensor.
Press for
more than 3
seconds to enter
initial setting
mode
Select the sensor connected. Default = PT100
Temperature unit. Default = °C
Upper limit of temperature range
Lower limit of temperature range
The control modes include: PID, ON/OFF, MANUAL.
Default = PID. Select “ON/OFF” here.
Select heating or cooling mode. Default = heating
Set up Alarm mode 1. Default = alarm output disabled
Set up Alarm mode 2. Default = alarm output disabled
ON/OFF of communication write-in. Default = OFF
Communication address
Communication speed
Data length (in bits)
Parity bit
Stop bit
