Delta OHM DO 9721 - P3 Baud Rate and P4 Year Setting

ENGLISH
87
KEY SIMBOLS LIT BESIDES
THE NUMBERS
FUNCTION
DESCRIPTION
P3+ = set Baud Rate
P4+ = set year
- P3 -
When ENTER is pressed with P3
on the display, the Baud Rate of
the RS232C serial transmission
may be modified.
The s and t keys are used to
select the desired value.
The possible values are:
19.2 = 19200 Baud
9.6 = 9600 Baud
4.8 = 4800 Baud
2.4 = 2400 Baud
1.2 = 1200 Baud
0.6 = 600 Baud
0.3 = 300 Baud
Finally press ENTER to return to
normal operation, or press the
PROG key to move on to step P4.
- P4 -
When ENTER is pressed with P4
on the display, the year value may
be set or changed.
The s and t keys are used to
select the desired year.
Then press PROG to move on to
step P5 (the ENTER key is not
active).
